Electromechanical Hydraulic Pharma Lifter Fixed Granulation In Pharma Industry 600L

Electromechanical-hydraulic Integrated Fixed Lifting Granulator With Fall Protection

Description:

The machine consists of a lifting system, a vacuum feeder, a temporary storage bin, a granulator, and an electro-hydraulic control system. During operation, the vacuum conveying pipeline is connected, and vacuum feeding is initiated. The material is conveyed via vacuum to the temporary storage bin to complete the feeding process. After the lifting device is activated to a certain height, the discharge device is connected, and the granulation process is initiated. The granulated material is then transferred to the next process.

It combines multiple functions such as material lifting, crushing and granulation, and dust-free conveying, effectively reducing dust pollution and material loss.This ensures the airtightness of materials throughout the entire process, reducing the risk of dust and cross-contamination, while also efficiently achieving uniform particle size control, thus facilitating clean, continuous, and low-loss automated operations in solid dosage form production. It is one of the key pieces of equipment for achieving efficient, clean, and continuous production in solid dosage form manufacturing.

Application:

This machine is mainly used for the transfer and feeding of solid materials in the pharmaceutical industry. It can be used in conjunction with fluidized bed dryers and fluidized bed granulators, and can directly process the material in the fluidized bed granulator into the required granules and put them into the main mixing tank, effectively eliminating dust and cross-contamination, reducing labor intensity, and improving work efficiency. At the same time, this machine is widely used in the chemical, food and other industries.

Specification:

Feature Advantage:

1. Integrated electromechanical-hydraulic design, compact size, stable operation, and reliable safety.

2. Equipped with safety protections such as lifting limit switches and hopper level detection.

3. Sealed material transfer prevents dust leakage and cross-contamination.

4. Modular design for convenient maintenance and operation.

5. Enhanced vacuum feeding reduces operational labor intensity and meets various granulation process requirements.

FAQ:

Q1: What types of pharmaceutical equipment do you manufacture?

We primarily manufacture a series of equipment for crushing, mixing, granulation, drying, coating, and cleaning, and provide complete production line solutions for industries such as health products, food, new energy, and chemicals.

Q2: Do you offer customized solutions?

Absolutely. We can customize equipment dimensions, capacity, control systems, material contact parts, feeding/discharging methods, and automation levels based on your specific production requirements.

Q3: Can your equipment comply with GMP requirements?

Yes. Our equipment is designed and manufactured in accordance with GMP standards. We use high-quality stainless steel materials (SS304 or SS316L), sanitary welding techniques, and easy-to-clean structures to ensure compliance with pharmaceutical production requirements.

Q4: What industries can use your equipment?

· Pharmaceutical manufacturing

· Nutraceutical production

· Food processing

· Chemical industries

· Biotechnology applications

Q5: Do you provide installation and commissioning services?

Yes. We offer installation guidance, commissioning support, operator training, and technical consultation. Remote support and on-site services are available depending on project requirements.

Q6: How do I choose the right machine model?
Our engineering team can recommend the most suitable model based on:
· Product characteristics
· Batch size
· Production capacity
· Facility layout
· Automation requirements
· Regulatory standards
Simply contact us with your requirements for a free consultation.

Q7: What is the lead time for production?

The specific delivery time depends on the machine type and configuration. The exact delivery cycle will be confirmed during the quotation process.

Q8: How do you ensure product quality?

Each machine undergoes the following processes:

Raw material inspection

Precision machining

Functional testing

Quality inspection and Factory Acceptance Testing (FAT)

Only qualified equipment is delivered to the customer.
