Automatic Hopper Lifting And Feeding Machine Conforms With GMP Standards
Description:
This machine mainly consists of a chassis, rotating column, lifting system, and control system. During operation, the lifting frame is first pushed forward, then the lifting button is activated, raising the material bucket. After the rotating column connects seamlessly with the feeding equipment, the discharge butterfly valve is opened, allowing the material to be transferred in a sealed manner to the next process.The entire transfer process is conducted in a closed system to prevent dust from flying and cross-contamination of materials, ensuring production safety and product purity.
The hopper lifting feeder is an automated vertical material conveying device specifically designed for the pharmaceutical, food, and chemical industries. Its core process is docking → lifting → rotating → docking and discharging, achieving sealed, dust-free transfer of powdery/granular materials without cross-contamination.The lifting height, rotation angle, and hopper specifications can be customized according to customer production needs to adapt to different workshop layouts.
Specification:
| Model |
|
Net load
|
Total power
|
|
|
L
|
W
|
R
|
H3
|
H2
|
H1
|
Kg
|
Kw
|
|
NTD200
|
1775
|
660
|
850
|
2500
|
3800
|
4000
|
200
|
1.5
|
|
NTD400
|
1934
|
660
|
950
|
2500
|
3800
|
4000
|
400
|
2.2
|
|
NTD600
|
2154
|
660
|
1050
|
2500
|
4000
|
4200
|
600
|
2.2
|
|
NTD800
|
2154
|
660
|
1050
|
2500
|
4100
|
4300
|
800
|
2.2
|
|
NTD1000
|
2373
|
730
|
1200
|
2500
|
4200
|
4400
|
1000
|
3
|
|
NTD1200
|
2423
|
730
|
1200
|
2500
|
4300
|
4500
|
1200
|
3
|
|
NTD1500
|
2423
|
730
|
1200
|
2500
|
4500
|
4700
|
1500
|
3
|
|
NTD1800
|
2448
|
730
|
1200
|
2500
|
4600
|
4800
|
1800
|
3
|
|
NTD2000
|
2448
|
730
|
1200
|
2500
|
4700
|
4900
|
2000
|
3
|
Application:
It is widely used in the solid material conveying process in industries such as pharmaceutical, food, health products, and fine chemicals, and is especially suitable for the material transfer from turnover hoppers to production equipment in the production process of tablets, capsules, and granules.It can be used with various pharmaceutical equipment such as mixers, tablet presses, capsule filling machines, and fluidized bed dryers, and is compatible with standard hoppers of different specifications.
Feature Advantage:
1. Enclosed material transfer system, preventing dust spillage and cross-contamination.
2. Automatic lifting, rotation, and alignment unloading significantly reduces manual handling intensity and improves production efficiency.
3. Equipped with fall protection, overload protection, and emergency stop devices, ensuring smooth and low-noise operation, and is simple and easy to use.
4. Easy to clean, with no dead corners, meeting the clean production standards of the pharmaceutical and food industries.
