V-type Mixer Specifically Designed For Mixing Dry Powders
Description:
The V-Type Mixer is a high-efficiency industrial blending machine specially designed for uniform mixing of dry powder and granular materials. Featuring a unique V-shaped double-cylinder structure, this equipment adopts gravity diffusion mixing principle with no dead mixing angles, enabling thorough and homogeneous material blending. It is widely applicable for pharmaceutical, food, chemical, cosmetic and metallurgy industries, perfectly meeting the mixing requirements of various dry materials.Crafted with high-quality stainless steel, the mixer features smooth surface, corrosion resistance and easy cleaning, complying with GMP production standards.
The stable rotating operation ensures low noise, low energy consumption and no material leakage. Equipped with flexible speed regulation and reliable safety protection devices, it supports adjustable mixing time and rotating speed to adapt to different material characteristics and production demands. Compared with traditional mixing equipment, this V-type mixer delivers higher mixing uniformity, no material segregation and stable working performance. With compact structure, simple operation and convenient maintenance, it is an ideal conventional mixing equipment for batch industrial production, greatly improving production efficiency and product quality consistency.
Application:
The V-Type Mixer is a versatile industrial mixing device tailored for dry powder and granular material blending, covering a wide range of industrial scenarios. It is extensively used in the pharmaceutical industry for mixing raw medicine powders and auxiliary materials, in the food industry for blending food additives, grain powders and seasoning ingredients, as well as in chemical, cosmetic, metallurgical and new energy industries. The equipment is suitable for mixing various dry materials with different densities and particle sizes, especially ideal for batch uniform mixing of materials that require no pollution and high purity. It can adapt to both small-batch laboratory trials and large-scale industrial mass production, satisfying diverse production and processing needs.
Specification:
|
Model
|
Total Volume (L)
|
Working Volume (L)
|
Rotating Speed (r/min)
|
Mixing Uniformity
|
Motor Power (kw)
|
Net Weight (kg)
|
|
VHJ-50
|
50
|
30
|
0-30
|
≤±2%
|
0.75
|
80
|
|
VHJ-100
|
100
|
60
|
0-25
|
≤±2%
|
1.1
|
120
|
|
VHJ-200
|
200
|
120
|
0-20
|
≤±2%
|
1.5
|
200
|
|
VHJ-300
|
300
|
180
|
0-18
|
≤±2%
|
2.2
|
280
|
|
VHJ-500
|
500
|
300
|
0-15
|
≤±2%
|
3.0
|
450
|
Feature Advantage:
1. Adopts a unique V-shaped double-barrel structure and gravity diffusion mixing principle. There are no mixing dead zones during operation, which effectively prevents material segregation and realizes even mixing of materials with different particle sizes and densities.
2. The whole machine is made of high-quality pharmaceutical and food-grade stainless steel. The smooth inner and outer surfaces are wear-resistant, corrosion-resistant, easy to clean and disinfect, and fully meet GMP production standards with no cross-contamination.
3. The equipment runs smoothly with low noise, low power consumption and zero material leakage. The reliable transmission system ensures long-term continuous and stable working performance for industrial batch production.
4. It supports adjustable rotating speed and customizable mixing time. Operators can flexibly set working parameters according to different material characteristics and production requirements to achieve optimal mixing results.
FAQ:
Q1: What types of pharmaceutical equipment do you manufacture?
We primarily manufacture a series of equipment for crushing, mixing, granulation, drying, coating, and cleaning, and provide complete production line solutions for industries such as health products, food, new energy, and chemicals.
Q2: Do you offer customized solutions?
Absolutely. We can customize equipment dimensions, capacity, control systems, material contact parts, feeding/discharging methods, and automation levels based on your specific production requirements.
Q3: Can your equipment comply with GMP requirements?
Yes. Our equipment is designed and manufactured in accordance with GMP standards. We use high-quality stainless steel materials (SS304 or SS316L), sanitary welding techniques, and easy-to-clean structures to ensure compliance with pharmaceutical production requirements.
Q4: What industries can use your equipment?
· Pharmaceutical manufacturing
· Nutraceutical production
· Food processing
· Chemical industries
· Biotechnology applications
Q5: Do you provide installation and commissioning services?
Yes. We offer installation guidance, commissioning support, operator training, and technical consultation. Remote support and on-site services are available depending on project requirements.
Q6: How do I choose the right machine model?
Our engineering team can recommend the most suitable model based on:
· Product characteristics
· Batch size
· Production capacity
· Facility layout
· Automation requirements
· Regulatory standards
Simply contact us with your requirements for a free consultation.
Q7: What is the lead time for production?
The specific delivery time depends on the machine type and configuration. The exact delivery cycle will be confirmed during the quotation process.
Q8: How do you ensure product quality?
Each machine undergoes the following processes:
Raw material inspection
Precision machining
Functional testing
Quality inspection and Factory Acceptance Testing (FAT)
Only qualified equipment is delivered to the customer.
